YOELEO
R12 DB Dragon Limited Edition
UCI Approved: Yes
Frameset: R12 Frame+Fork+Handlebar+Seatpost
Frame Sizes: 43cm,47cm,50cm,52cm,54cm,56cm,59cm
Handlebar Size: 380mm,400mm,420mm,440mm
Stem Size: 90mm/100mm/110mm/120mm
Material: High Modulus Toray 800 Carbon Fiber
Color: Hemidium / Emerald Green / Custom Painting
Carbon Weave: UD
Groupset Compatible: Machine and Di2 compatible
BB: BB386
Rear Dropout: 12*142 Thru Axle
Rear derailleur hanger: Replaceable
Headtube: 1-1/2” Straight
Fork: Aero Disc Brake Fork,Flat Mount,12*100 Thru Axle
Fork Offset: 45˚
Brake: Flat Mount Disc Brake
Max Tire Width: 32mm
Cable: Internal cable
Frame Weight:
Hemidium 1020g (47cm) +/-50g
Emerald Green 1030g (47cm) +/-50g
Raw 970g (47cm) +/-50g
Fork Weight: 400+/-10g
Accessories: Handlebar Spacers 3mm: 1PC, 5mm: 1PC, 10mm: 2PCS, Headset Bearing Cap 10mm: 1PC
Front Axle 1PC, Rear Axle 1PC
Limited Rider Weight: 110KG
Warranty: 6 Years
Warranty
Standard Coverage: 6-year warranty
Extended Option: AdditionalLifetime warrantyavailable for US$300
Crash Replacement Policy
YOUR SAFETY MATTERS
While we sincerely hope you won't require it, we provide a 30% crash replacement discount on all handlebars and spares in the unfortunate event of a crash. Reach out to us, and we'll strive to assist you promptly, ensuring you can get back on the road and ride again as soon as possible.
Introducing the R12 Dragon Edition: Where ancient legend meets modern engineering. Witness the awakening of the dragon, intricately designed to celebrate the Year of the Dragon. Embark on a journey where every pedal stroke resonates with the strength and prosperity of the mythical creature that has inspired generations. Get ready to ride with luck, power, and the spirit of the dragon guiding your path.
Dragon Limited Edition
Feel the power of the dragon seeping through your R12.
Aerodynamics Meets Comfort
Experience the pinnacle of cycling with the Yoeleo R12, where cutting-edge aerodynamics and unparalleled comfort converge. a sleek carbon fiber frame and optimized carbon layout, the R12 offers a smooth and responsive ride. Whether sprinting or enduring long distances, it delivers an exhilarating yet comfortable journey, redefining your ride every pedal of the way.
YOELEO PROROUTE SYSTEM
The ProRoute Stem System introduces dual mounting solution for internal cable routing, catering to both the complete internal cable routing (Y-ICR) and the semi-internal cable routing (S-YICR) with sleek, removable spacers. This design ensures hassle-free installation.
AERODYNAMIC DESIGN FOR UNRIVALED SPEEDS
The Yoeleo R12 boasts a sleek, aerodynamic frame that minimizes drag and maximizes speed. Glide through the air and achieve your personal best on every ride with the R12's streamlined design.
ENHANCED CARBON FIBER LAY-UP FOR OPTIMAL STIFFNESS
Experience the perfect balance of stiffness and lightweight performance with the R12's enhanced carbon fiber lay-up. This upgraded feature offers increased rigidity without adding extra weight, ensuring a responsive and nimble ride on every terrain.
THE BIGGER, THE BETTER
Want to spice up your workout with those uphill's or go for light gravel? Simply replace the current tire with 32c and chunkier all-terrain tire. Yoeleo R12 now supports wide road tires including 32mm of clearance for increased traction and comfort on the road
All-Round Performance
Master Every Mile: Your Ultimate Ride for Speed and Endurance
Frame technology
ProMoldCore Technology
The conventional manufacturing method that is still common practice with most companies today brings a lot of issues. Conventional methods causes undulations on the internals of the frame and even increases weight, making it difficult to achieve performance according to the specified carbon sheet specifications.Unlike traditional methods such as nylon bladders, ProMoldCore manufacturing technology allows for a more stable molding of the inside of the frame thanks to latex's flexibility and stretchability.We believe that inside out beauty applies for everything, especially for our framesets. By utilizing ProMoldCore technology, the outside and inside of a carbon road frame are of the same quality, resulting in an inner surface that is as smooth and wrinkle-free as the outer surface.The use of latex increases the pressure of the molded latex bag, smoothing the internal finish, improving the compressibility of the compound, reducing resin waste, and allowing for more complex shapes to be made.
Handlebar Tech
ProMoldCore and ProOne Technology
CRAFTED WITH PROMOLDCORE
In the same vein, the implementation of ProMoldCore in fabricating our handlebars has earned them renown for their stiffness. Experience hassle-free cable installation as the latex molds the bar's interior, ensuring a seamless cable routing installation with a sleek, smooth finish inside out.
ProOne Technology:
One-piece, no-bond manufacturing utilizes high-grade carbon fiber and YOELEO precision layup technique to eliminate the added weight and flex found in traditionally bonded bars.
Integrated or Stem+Bar
We offer H9 intergrated or
ST1+H11 stem with bar option for R12
H9
Integrated Handlebar
Stem+Bar
ST1+H11
R12
Geometry
43 | 47 | 50 | 52 | 54 | 56 | 59 | ||
Size Recommendation | Rider Height | 155cm-163cm | 160cm-168cm | 165cm-173cm | 170cm-178cm | 175cm-183cm | 180cm-188cm | 185cm-193cm |
A | SEAT TUBE LENGTH(mm) | 430 | 450 | 470 | 490 | 510 | 530 | 560 |
B | TOP TUBE LENGTH(mm) | 505 | 516 | 528 | 540 | 552 | 567 | 582 |
C | REACH(mm) | 370.6 | 375.9 | 378.6 | 381 | 386 | 388.2 | 393 |
D | STACK(mm) | 501.6 | 505 | 520.9 | 536.9 | 550 | 567.2 | 581.6 |
E | HEAD TUBE LENGTH(mm) | 100 | 100 | 115 | 130 | 145.7 | 160 | 175 |
F | SEAT TUBE ANGLE | 75° | 74.5° | 74.0° | 73.5° | 73° | 72.5° | 72.0° |
G | HEAD TUBE ANGLE | 70.5° | 71.5° | 72° | 72.5° | 73° | 73° | 73° |
H | BOTTOM BRACKET DROP(mm) | 72 | 72 | 72 | 72 | 72 | 72 | 72 |
I | CHAIN STAY LENGTH(mm) | 415 | 415 | 415 | 415 | 415 | 415 | 415 |
J | FRONT CENTER(mm) | 572.9 | 570.7 | 574.2 | 577.1 | 583.5 | 588.9 | 598.1 |
K | WHEELBASE(mm) | 977 | 974.8 | 978.3 | 981.3 | 987.6 | 993.2 | 1002.4 |
L | FORK RAKE(mm) | 43 | 43 | 43 | 43 | 43 | 43 | 43 |
M | FORK LENGTH(mm) | 371 | 371 | 371 | 371 | 371 | 371 | 371 |
